One of the most common problems pool owners run across when maintaining and serving their swimming pool is a leaking backwash valve. The backwash valve is the valve which is mounted on either the top or side of your filter tank and are specifically used clean sand filters or DE filters.
One of the most popular filter manufactures in the world is Hayward Pool Products who also makes quite a few backwash valves. Based on the Hayward valve you have the fix varies slightly. This guide will help you determine which Hayward valve you have and then determine the proper fix for your situation. Step 2 If you are having trouble finding the valve # on the label then you may be able to find a SP or SPX part # molded into the plastic of the body of the valve or the handle. Feel free to post a comment at the bottom of this guide with as much information about your filter as possible and we should be able to help identify your valve. Helpful information for us would be any part #’s off of the valve, the filter manufacture name, the filter model name, filter model #, filter square footage, number of positions the valve can be set to, plumbing size going into the valve and filter type (i.e. Sand filter or D.E filter).
Filter e-13 valves hayward multiport sp-740de 2' d.e. Vari-flo valve - 2' hayward slide valve 2' 14 key item # description mfg. This guide will walk you through the process of fixing your leaking Hayward. Hayward valves which is leaking. Hayward valve is called a slide.
FILTER - For normal filtering and regular vacuuming. BACKWASH - For cleaning filter sand bed of accumulated debris. RINSE - Use after completing.
Any or all of this information will help out a lot. Step 3 If you have one of the following Hayward valves which is leaking then the appropriate fix would be to replace the spider gasket within the valve. Here is a detailed guide on, this guide will walk you through all the steps needed to fix your backwash valve. The following can be fixed by simply replacing the spider gasket. The appropriate spider gasket for the valves below is the. SP711-13, SP710XALL, SP7122, SP7121, SPX0710X32, SP0710X62, SP0710XR50 The following can be fixed by simply replacing the spider gasket. The appropriate spider gasket for the valves below is the with the exception of the SP0740DE which uses the spider gasket.
SP715ALL, SPX715X32, SP0715X62, SP0715XR50, SP071621, SP071620T, SP0740DE If you have any of the model #'s above then purchase the or spider gasket and move on to our for easy step by step instructions on replacing the gasket. If you have the SP0714T valve or any other model #'s then move on to step # 4 of this guide. Step 4 The most common Hayward backwash valve is the which is used on many of the Hayward top mount sand filters. If you have the SP0714T valve then the spider gasket cannot be replaced as it comes glued into the diverter on the valve. The appropriate fix for a leaking SP0714T valve would be to replace the which comes with the spider gasket glued into it.
This is an easy enough fix, you would just need to remove the cover and handle assembly from the current valve and and swap out with the new diverter. Inyopools Posted: 13:41 PM Inyo Product Specialist Eric - 1. If you have a damaged spider gasket, I do not think that would cause a problem when the pump is off. Water leaking at the shaft would be caused by a worn shaft seal in the Impeller and face plate. It depends on the valve. Some valves require two but others require one.
If you take your valve apart and only see one washer, you can save the second washer that is included. 5th Edition Geology Glossary here. From the parts list for SP0716, it looks like you only have one washer placed above the spring.
Eric Posted: 11:55 AM I have 3 questions please. My valve is in filter position and I have a closed valve on the waste pipe. Can a leaking spider gasket cause air suction when pump is closed? When my pump is off I hear air suction at the valve shaft. Can a leaking spider gasket be the cause of water leaking at the shaft, or can this only be caused by defective shaft o-rings?
I notice that the metal washers with the shaft spring come in a set of two. I opened my valve and could see only 1 metal washer, on top of the spring. Is this possible or should there always be another washer underneath the spring. My valve is SP071620T. Inyopools Posted: 12:53 PM Inyo Product Specialist Mike S. - I'm not sure what your question is.
Are you asking if the leak can be fixed by replacing the top Key Cover and Handle Assembly or if you have to replace the whole MPV? Let me start by saying there are three major replacement parts for the common Hayward MPVs: the whole Multiport Valve (MPV) itself; the Key, Cover, and Handle Assembly (KCHA) and the Key Assembly (KA) itself. The KCHA is the upper half of the MPV and the KA is the lower half of the KCHA. Most repairs are fixed by replacing only the KA. In your question, you mix replacement parts between the SP0714T MPV and the SP0710 MPV. For the SP0714T MPV, the KCHA is SPX0714BA and its KA is SPX0714CA. For the SP0710 MPV, the KCHA is SPX0710BA17 and the KA is SPX0710XD.
